Name: Digital Earth Leakage Relay, 96x96mm Panel Mount, 30mA to 3A, Class 5FS without RS485: Elmeasure iELR 300
Brand: Elmeasure
SKU: 36118
Availability: InStock

Digital Earth Leakage Relay, 96x96mm Panel Mount, 30mA to 3A, Class 5FS without RS485: Elmeasure iELR 300

Elmeasure iELR 300: Digital Earth Leakage Relay, 96x96mm Panel Mount, 30mA to 3A, Class 5FS without RS485

Safeguard from fatal electrical shocks and fire hazards.
Prevent equipment damage and the risk of unplanned downtime.
Helps in diagnosing loose connections and damaged insulations.

Description

Digital Earth Leakage Relay, 96x96mm Panel Mount, 30mA to 3A, Class 5FS without RS485: Elmeasure iELR 300

True RMS measurement
Clearance and creepage distance meets UL 61010 safety standard
Intelligent Protection – trip time is inversely proportional to fault current
Field programmable trip current and trip time through front panel keys with password protection
Continuous leakage current display (Programmable) – Leakage current is continuously displayed to enhance the user to understand of the quality of the Electrical network / Machine/troubleshooting online. This can be disabled through setup if required
Continuous display of trip leakage current (Programmable) – In case of tripping, iELR captures and displays the tripped current with 4 Digits resolution, which helps the user to analyze and correct the problem. This can be disabled through setup if required
Continuous scrolling display for set current and set time
Manual test and reset keys l RS485 communication option
Auto Configuration through communication
Reset through communication in trip condition
Protects control panels and switchboards from flame leakage
Protects motors/transformers/feeders/generators etc., from earth leakage
Hazardous and sensitive industries like oil refineries/pulp industries / electrical distribution etc. can be protected
Complete protection for control engineering and mining industry

Advantages

The microcontroller-based design provides a higher technological advantage
Peak detection and value display help in the analysis and corrective action
Password protection for security against mishandling
Current sensitivity wider range 30mA – 3A and 300mA to 30A no limitations on set current (30mA to 30A coming soon)
Programmable trip time 30ms – 30s with the wider choice to suit different industry
Selection through soft keys (No DIP switches) provides better IP protection and longer life
Continuous earth leakage value display helps online loss analysis (Programmable)
Intelligent tripping based on T 1/A gives faster and more reliable protection
Auto scrolling of trip information and peak fault current provides better analysis

Technical Specifications


Display:	4 Digit 4 Digit Input Current: 30mA to 3A or 300mA to 30A (30mA – 30A coming soon)
Trip Current:	Programmable
Tripping time:	100 mS – 30 sec.
Contact Rating:	2Amps @ 240V AC / 24V DC
Accuracy:	Class 5.0 FS (Default), Optional Class 2.0 FS
Auxiliary Supply:	80 – 300V AC/DC, 4VA Max.
CBCT:	Round, Rectangular
Core Balance:	CT type: Tape wound limited round size, option for the epoxy coated and plastic version.
Communication:	Parity: Odd, Even, None (Preferred Even)
RS485 Interface:	Baud rate: 4800 bps to 38400 bps (Preferred 9600 bps)
(Optional) Isolation:	2000 volts AC isolation for 1 minute between communication and other circuits.
Torque:	1 N-m for Panel Mount, 0.2 N-m for DIN-rail
Wire Gauge:	11 AWG

Product Variants

Model	Description	Cat Code
Plastic Enclosure Round CBCT
CBCT-35mm	Plastic Enclosure Round CBCT	CBCTP0060XX0450
CBCT-ID 70mm	Plastic Enclosure Round CBCT	CBCTP0100XX0441
CBCT-120mm	Plastic Enclosure Round CBCT	CBCTP0250XX0444
CBCT-210mm	Plastic Enclosure Round CBCT	CBCTP0300XX0445
Tape Wound Round CBCT
CBCT-60mm	Tape Wound Round CBCT	CBCTT0060XX0435
CBCT-100mm	Tape Wound Round CBCT	CBCTT0100XX0436
CBCT-150mm	Tape Wound Round CBCT	CBCTT0150XX0437
CBCT-200mm	Tape Wound Round CBCT	CBCTT0200XX0438
CBCT-250mm	Tape Wound Round CBCT	CBCTT0250XX0439
CBCT-300mm	Tape Wound Round CBCT	CBCTT0300XX0440
Tape Wound Rectangular CBCT
CBCT-ID 150 × 50mm	Tape Wound Rectangular CBCT	CBCT0150050483
CBCT-ID 200 × 100mm	Tape Wound Rectangular CBCT	CBCTT0200100537
CBCT-ID 250 × 50mm	Tape Wound Rectangular CBCT	CBCT0250050483
CBCT-250 × 100mm	Tape Wound Rectangular CBCT	CBCTT0250100446
CBCT-ID 300 × 50mm	Tape Wound Rectangular CBCT	CBCT0300050483
CBCT-300 × 100mm	Tape Wound Rectangular CBCT	CBCTT0300100483
CBCT-ID 350 × 50mm	Tape Wound Rectangular CBCT	CBCT0350050483
CBCT-ID 350 × 100mm	Tape Wound Rectangular CBCT	CBCTT0350100484
CBCT-350 × 150mm	Tape Wound Rectangular CBCT	CBCTT0350150447
CBCT-ID 400 × 150mm	Tape Wound Rectangular CBCT	CBCTT0400150490
CBCT-400 × 200mm	Tape Wound Rectangular CBCT	CBCTT0400200485
CBCT-500 × 200mm	Tape Wound Rectangular CBCT	CBCTT0500200448
CBCT-ID 600 × 200mm	Tape Wound Rectangular CBCT	CBCTT0600200477
CBCT-ID 750 × 250mm	Tape Wound Rectangular CBCT	CBCTT0750250522
