Micro Modular Rail Mount PLC system- SELEC MiBRX-2M-1-0-0-24VAC
₹3,935.00
MiBRX 2M sized Modular PLC- 2 slots, 3DI
- 2M Sized, Rail mount modular PLC with multiple pluggable LED Display options
- Offers Flexible IO Card selection
- RTC with time switch functions (Optional)
Description
Description
MiBRX RAIL is Micro Modular Rail Mount PLC system with fixed & pluggable IO slots 2, 4 & 6 slots. As per product variants it also has Modbus master & slave communication along with pluggable display, suitable to user as per the applications… Can be extended for HMI interface low cost and self-powered independent or full-fledged graphical touch HMI’s, offering solutions for process monitoring and control and data analytics.
Brief Specifications: Micro Modular Rail Mount PLC system: SELEC MiBRX-2M-1-0-0-24VAC
| Display Type | 7 Segment LED Display |
| Supply Voltage | 24VAC/24VDC |
| Size | 35(W) x 90(H) x 60(D)mm |
| Digital Inputs | 3 |
| Analog Inputs | As per IO Card Selection |
| Digital Outputs | As per IO Card Selection |
| Analog Outputs | As per IO Card Selection |
| No. of Slots | 2 |
| RTC With Time Switch Function | Optional |
| Code Memory | 112Kb |
| Communication Interface | RS485 Modbus RTU Protocol (Slave ) |
| Expansion | No |
| Mounting Type | Din Rail |
| FI / Maximum Counting Frequency | 1( 5kHz) |
MiBRX PLC – Rail Mount: Product Variants (2M, 4M, 6M)
- Modular Display
- 2/4/6 configurable MiBRX IO SLOTS
- Optional MODBUS Master/ expandable
- Optional RTC
- 230VAC/ 24VDC Power Supply
| Product Code | Description |
| MiBRX-2M-1-0-0-24VAC | MiBRX 2M Base module – 2 slots, 3DI |
| MiBRX-2M-1-0-0-24VDC | MiBRX 2M Base module – 2 Slots, 3DI (incl 1FI) |
| MiBRX-4M-1-0-0-230V | MiBRX 4M Base module – 4 Slots, 5DI (incl 1FI, 1AI-V), NTC |
| MiBRX-4M-1-1-1-230V | MiBRX 4M Base module – 4 Slots, 5DI (incl 1FI, 1AI-V), NTC, RTC, Master |
| MIBRX-4M-1-0-0-24VDC | MiBRX 4M Base module – 4 Slots, 5DI (incl 1FI, 1AI-V), NTC |
| MIBRX-4M-1-1-1-24VDC | MiBRX 4M Base module – 4 Slots, 5DI (incl 1FI, 1AI-V), NTC, RTC, Master |
| MiBRX-6M-1-1-1-230V | MiBRX 6M Base module – 6 Slots, 11DI (incl 1FI, 1AI-V), + 4RO, NTC, RTC, Master |
| MIBRX-6M-2-1-1-0-1-24VDC | MiBRX 6M Base module – 6 Slots, 12DI, 24V Power supply with Isolation, Master, ETHERNET & RTC |
| MiBRX-DSP-2M-0-1-06-A | MiBRX Display 2M – Blind, 6 LED |
| MiBRX-DSP-2M-7-1-04-A | MiBRX Display 2M – 7 seg (4 digit), 6 LED |
| MiBRX-DSP-4M-0-1-06-A | MiBRX Display 4M – Blind, 6 LED |
| MiBRX-DSP-4M-8-2-08-A | MiBRX Display 4M – LCD (8×2) |
| MiBRX-DSP-6M-8-2-08-A | MiBRX Display 6M – LCD (8×2) |
Additional information
Additional information
| Brand |
Selec |
|---|---|
| HSN Code |
85363000 |
