Load Disconnector-Three Phase (6DIN) with Wi-Fi- Elmeasure LD2510D
₹13,925.00
Load Disconnector
The LD Series Load Disconnector combines energy metering with reliable protection features. These disconnectors monitor voltage, current, and power factors, automatically disconnecting loads during faults or overloads. Ideal for industrial and commercial applications, the LD Series offers easy installation via DIN rail or panel mounting, with self-powered operation for three-phase systems.
Add monitoring and control capabilities to the operational processes of your plant. An integrated device for an easy on-the-go load management.
- Replaces multiple devices, offering metering, relay, time switch, gateways, stabilizers and contactor functions.
- Accommodates direct connection up to 100A loads (80A inductive load).
- Provides real-time information on basic, energy and power parameters. Offers energy tracking via LED pulses as well.
- Offers dynamic communication interfaces: RS485 Modbus RTU, Wi-Fi, MQTT for remote/IoT load management.
- Guards against voltage variations, single phasing, phase reversal and current unbalances.
Applications
- Any equipment less than 100A (80A inductive load)
- Industrial and commercial metering
- Small-scale industries.
- Building and factory automation
- Any home appliance protection, replaces all stabilizers.
Description
Enhance plant efficiency with advanced monitoring and control solution, 3-Phase Load Disconnector with Wi-Fi Elmeasure LD2510D
Elmeasure Load Disconnector series offers a combined solution of Three-Phase Load Disconnector and a Three-Phase Power/Energy Metering solution for the market. It features DIN rail mounting, high accuracy of Class 1.0/0.5, multifunction true RMS measurements, and an easy-to-read LCD display. It has a direct rated current of 100A (80A for inductive loads). This device is designed for use in four-pole systems (3Phase + Neutral) or 3 pole operating directly in 550V (LL) / 300V (LN) networks at frequencies ranging from 45Hz to 65Hz. With a 3-phase power supply, no external control power is required as it takes power internally.
Key features of Load Disconnector:
Integrated Functionality
- Replaces multiple devices, offering metering, relay, time switch, gateways, stabilizers and contactor functions.
- Reduces cost and wiring complexity.
Protection and Disconnection
- Built-in disconnection circuit with configurable protections.
- Guards against voltage variations, single phasing, phase reversal and current issues like current unbalances.
Communication and Control
- Enables load control via communication for optimized use apart from set threshold.
- Offers dynamic communication interfaces: RS485 Modbus RTU, Wi-Fi, MQTT.
Operational Modes
- User-selectable NC and NO modes for safe or alarming connections.
- Avoids equipment damage with overload protection
Energy Efficiency Insights
- Programmable levels display load efficiency and status.
- Monitors individual phase energy consumption for maintenance indication.
Display and Indicators
- Alphanumeric LCD display with LED indicators.
- Displays disconnection reasons and trip details.
- Monitor V, A, F, W, VA, PF, Wh, VAh, Load Hrs. and ON Hrs.
- Offers high Accuracy Class 1.0.
- Provides real-time information on basic, energy and power parameters. Offers energy tracking via LED pulses as well.
Remote control & IoT Capability
- Supports remote monitoring and control for an easy on-the-go load management.
- 5 slots of scheduling possible, avoid time switch.
Installation and Compatibility
- DIN rail mount for easy tool-free installation.
- Accommodates direct equipment connection up to 100A.
- Sealing option.
Configuration and Setup
- Easy setup with password protection and field programmability.
- Dynamic communication with configurable addresses.
Optional Features
- Dual energy reading for EB & DG (Disconnection based on any source)
- Communication with isolated RS485 serial interface (default), Wi-Fi optional
- Scheduler option 5 slots (coming soon)
Product Variants
- CATCODE: LD2510D13800, MFM, Class 1.0, WiFi, 80A Inbuilt
- CATCODE: LD2510D11800, MFM, Class 1.0, RS485, 80A Inbuilt
Additional information
| Brand |
Elmeasure |
|---|---|
| Category Code |
ELR300P91370000 |
